HONDA C35A2

Engine technical data
Technical data		Valve control		Timing control	Timing Belt
Manufacturer		Engine type	V	Compression
Engine code	C35A2	Fuel type	Petrol	Bore ^mm	90
Power ^kw/hp	151/205	Fuel mixture formation	Intake Manifold Injection/ Carburettor	Stroke ^mm	91
Engine volume ^cm³	3474	Charging		Crankshaft bearing
Cylinders	6	Engine block type		Cooling	water-cooled
Valves	24	Cylinder head type	SOHC/OHC

Technical data
Manufacturer
Engine code C35A2
Power ^kw/hp 151/205
Engine volume ^cm³ 3474
Cylinders 6
Valves 24
Valve control
Engine type V
Fuel type Petrol
Fuel mixture formation Intake Manifold Injection/ Carburettor
Charging
Engine block type
Cylinder head type SOHC/OHC
Timing control Timing Belt
Compression
Bore ^mm 90
Stroke ^mm 91
Crankshaft bearing
Cooling water-cooled

Vehicles

HONDA LEGEND III (KA) 3.5 i 24V (KA9) HONDA LEGEND III (KA) 3.5 i 24V (KA9)

Found 44 products:

Oil Sump Gasket

Seal Ring, oil drain plug - 243.600 ELRING

Brand: ELRING

Part Number: 243.600

Outer Diameter [mm]: 22
Thickness [mm]: 2
Inner Diameter [mm]: 14

Oil Filter

Oil Filter - ADH22114 BLUE PRINT

Brand: BLUE PRINT

Part Number: ADH22114

Outer Diameter [mm]: 69
Sealing Ring Diameter [mm]: 62.5
Height [mm]: 86.5

Oil Filter

Oil Filter - ADS72101 BLUE PRINT

Brand: BLUE PRINT

Part Number: ADS72101

Outer Diameter [mm]: 80
Height [mm]: 80
Filter type: Screw-on Filter

Valve Stem Seal

Seal Ring, valve stem - 130.560 ELRING

Brand: ELRING

Part Number: 130.560

Colour: Green
Valve Stem Diameter [mm]: 5.5
Outer Diameter [mm]: 13

Radial Oil Seal/Set

Shaft Seal, crankshaft - 293.946 ELRING

Brand: ELRING

Part Number: 293.946

Outer Diameter [mm]: 50
Height [mm]: 8
Inner Diameter [mm]: 35

Radial Oil Seal/Set

Shaft Seal, crankshaft - 590.797 ELRING

Brand: ELRING

Part Number: 590.797

Outer Diameter [mm]: 98
Height [mm]: 10
Inner Diameter [mm]: 80

Valve Stem Seal

Seal Ring, valve stem - 130.860 ELRING

Brand: ELRING

Part Number: 130.860

Colour: Black
Valve Stem Diameter [mm]: 5.5
Outer Diameter [mm]: 13

Radial Oil Seal/Set

Shaft Seal, crankshaft - NJ242 PAYEN

Brand: PAYEN

Part Number: NJ242

Outer Diameter [mm]: 50
Height [mm]: 8
Inner Diameter [mm]: 35

Drain Screw

Sealing Plug, oil sump - 523.500 ELRING

Brand: ELRING

Part Number: 523.500

Spanner Size: 17 mm
Bolt Head-/Nut Design: Male Hex
Thread Size: M 14x1,5x15

Valve Stem Seal

Seal Ring, valve stem - 12014300 AJUSA

Brand: AJUSA

Part Number: 12014300

Outer Diameter [mm]: 10.9
Height [mm]: 10
Inner Diameter [mm]: 5

Valve Stem Seal

Seal Ring, valve stem - 12014200 AJUSA

Brand: AJUSA

Part Number: 12014200

Outer Diameter [mm]: 10.9
Height [mm]: 10
Inner Diameter [mm]: 5

Oil Sump Gasket

Seal Ring, oil drain plug - 22007400 AJUSA

Brand: AJUSA

Part Number: 22007400

Outer Diameter [mm]: 22
Thickness [mm]: 2
Inner Diameter [mm]: 14.5

Switch/Sensor

Sensor, coolant temperature - 33696 FEBI BILSTEIN

Brand: FEBI BILSTEIN

Part Number: 33696

Spanner Size: 13
Number of connectors: 1
Length [mm]: 41

Valve Guide/Stem Seal/Parts

Valve Guides - G3572 FRECCIA

Brand: FRECCIA

Part Number: G3572

Outer Diameter [mm]: 11.06
Inner Diameter [mm]: 5.5
Material: Grey Cast Iron

Drain Screw

Sealing Plug, oil sump - 523.480 ELRING

Brand: ELRING

Part Number: 523.480

Spanner Size: 17 mm
Bolt Head-/Nut Design: Male Hex
Alternative Repair Kit: 523.5

Radial Oil Seal/Set

Shaft Seal, crankshaft - 15013300 AJUSA

Brand: AJUSA

Part Number: 15013300

Outer Diameter [mm]: 50
Height [mm]: 8
Inner Diameter [mm]: 35

Switch/Sensor

Sensor, coolant temperature - 727067 NRF

Brand: NRF

Part Number: 727067

Sensor Type: NTC Sensor
Spanner Size: 12
Mounting Type: Bolted

Radial Oil Seal/Set

Shaft Seal, crankshaft - 15035700 AJUSA

Brand: AJUSA

Part Number: 15035700

Outer Diameter [mm]: 98
Height [mm]: 10
Inner Diameter [mm]: 80

Valve Guide/Stem Seal/Parts

Valve Guides - VAG92397 AE

Brand: AE

Part Number: VAG92397

Outer Diameter [mm]: 11.06
Inner Diameter [mm]: 5.53
Length [mm]: 47.5

Categories

Engine Oil - 32925 FEBI BILSTEIN

Brand: FEBI BILSTEIN

Part Number: 32925

Specification: ACEA A3/B4, ACEA E7, API CI-4/SL, CAT ECF-1-a/ECF-2, Cummins CES 20076, Cummins CES 20077, Cummins CES 20078, Deutz DQC-III, MAN 3275, MB 228.3, MB 229.1, MTU Type 2, Mack EO-M PLUS, Renault RLD-2, VW 501 01, VW 501 01/505 00, VW 505 00, Volvo VDS-3
SAE viscosity class: 15W-40
Capacity [litre]: 1
